1613A Series
Manufacturer: Belden Inc.
Beta
⌘K
COAX 75 OHM RG6 18AWG
| Part | Shield Material | Conductor Material | Dielectric Material | Shield Coverage | VoP, Velocity of Propagation | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Length [x] | Length [x] | Conductor Strand | Cable Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Jacket Color | Shield Type | Cable Group | Impedance | Jacket (Insulation) Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | Copper Coated Steel | Foam Polyethylene (FPE) | 77 % 100 % | 83 | 80 °C | -40 C | 0.18 in | 4.57 mm | 304.8 m | 1000 ft | Solid | Coaxial | 6.99 mm | 0.275 in | 18 AWG | White | Braid Foil | RG-6 | 75 Ohms | Poly-Vinyl Chloride (PVC) |
