DDL50 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB RCPT 50POS R/A SOLDER
| Part | Contact Type | Contact Finish | Contact Material | Current Rating (Amps) | Mounting Type | Flange Feature | Dielectric Material | Shell Size, Connector Layout | Features | Backset Spacing | Backset Spacing | Material Flammability Rating | Number of Rows | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Connector Type | Connector Style | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Signal | Gold or Gold GXT™ | Copper Alloy | 5 A | Through Hole Right Angle | Board Side (M3) | Thermoplastic | 5 | Mounting Brackets | 0.409 in | 10.4 mm | UL94 V-0 | 3 | Solder | -55 °C | 125 °C | 50 | Receptacle Female Sockets | D-Sub | |
Amphenol ICC (FCI) | Signal | Gold GXT™ | Copper Alloy | 5 A | Through Hole Right Angle | Housing/Shell (M3) | Thermoplastic | 5 | UL94 V-0 | 3 | Solder | -55 °C | 125 °C | 50 | Receptacle Female Sockets | D-Sub | 300 VDC | |||
Amphenol ICC (FCI) | Signal | Gold or Gold GXT™ | Copper Alloy | 5 A | Through Hole | Board Side (M3) | Thermoplastic | 5 | Grounding Indents | UL94 V-0 | 3 | Solder | -55 °C | 125 °C | 50 | Male Pins Plug | D-Sub |
