387-042 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 42POS 0.156
...
| Part | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Contact Finish | Material - Insulation | Contact Type | Termination Rows | Card Type | Read Out | Color | Flange Feature | Mounting Type | Contact Material | Number of Positions | Pitch [x] | Pitch [x] | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Features | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 2 | Non Specified - Dual Edge | Dual | Black | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Solder | 10 Áin | 0.25 Ám | 2 | ||||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 2 | Non Specified - Dual Edge | Dual | Black | Flush Mount Top Opening Unthreaded | Board Edge Straddle Mount | Copper Alloy | 42 | 0.156 in | 3.96 mm | Solder | 10 Áin | 0.25 Ám | 2 | Card Extender | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 2 | Non Specified - Dual Edge | Dual | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Solder | 10 Áin | 0.25 Ám | 2 | ||||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Wire Wrap | 10 Áin | 0.25 Ám | 1 | 42 | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Solder | 10 Áin | 0.25 Ám | 1 | 42 | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Wire Wrap | 10 Áin | 0.25 Ám | 1 | 42 | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole Right Angle | Copper Alloy | 42 | 0.156 in | 3.96 mm | Wire Wrap | 10 Áin | 0.25 Ám | 1 | 42 | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Wire Wrap | 10 Áin | 0.25 Ám | 1 | 42 | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 2 | Non Specified - Dual Edge | Dual | Black | 4-40 Threaded Insert Top Mount Opening | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Solder | 10 Áin | 0.25 Ám | 2 | ||||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | Female | Gold | Polyester Thermoplastic | Cantilever | 1 | Non Specified - Single Edge | Single | Black | Through Hole | Copper Alloy | 42 | 0.156 in | 3.96 mm | Wire Wrap | 10 Áin | 0.25 Ám | 1 | 42 | 3.25 mm | 0.128 in |
