1744446 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HDR ASSY, EP 2.5 RA, 12 POS., GW
| Part | Applications | Number of Positions Loaded | Mounting Type | Number of Positions | Shrouding | Number of Rows | Connector Type | Current Rating (Amps) | Fastening Type | Contact Finish - Post | Features | Contact Shape | Style | Termination | Insulation Height [z] | Insulation Height | Insulation Color | Voltage Rating | Contact Length - Post [x] | Contact Length - Post [x] | Contact Material | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Insulation Material | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | General Purpose Industrial Lighting | All | Right Angle Through Hole | 12 | Shrouded - 4 Wall | 1 | Header | 4.2 A | Friction Lock | Tin | Board Lock Glow Wire Compliant | Circular | Board to Cable/Wire | Kinked Pin Solder | 0.299 " | 7.6 mm | Natural | 250 VAC | 0.126 " | 3.2 mm | Copper Alloy | Male Pin | -55 C | 105 ░C | 2.5 mm | 0.098 in | Nylon Polyamide (PA) | UL94 V-0 |
TE Connectivity AMP Connectors | General Purpose Industrial Lighting | All | Right Angle Through Hole | 14 | Shrouded - 4 Wall | 1 | Header | 4.2 A | Friction Lock | Tin | Board Lock Glow Wire Compliant | Circular | Board to Cable/Wire | Kinked Pin Solder | 0.299 " | 7.6 mm | Natural | 250 VAC | 0.126 " | 3.2 mm | Copper Alloy | Male Pin | -55 C | 105 ░C | 2.5 mm | 0.098 in | Nylon Polyamide (PA) | UL94 V-0 |
 TE Connectivity AMP Connectors | General Purpose Industrial Lighting | All | Right Angle Through Hole | Shrouded - 4 Wall | 1 | Header | 4.2 A | Friction Lock | Tin | Board Lock Glow Wire Compliant | Circular | Board to Cable/Wire | Kinked Pin Solder | 0.299 " | 7.6 mm | Natural | 250 VAC | 0.126 " | 3.2 mm | Copper Alloy | Male Pin | -55 C | 105 ░C | 2.5 mm | 0.098 in | Nylon Polyamide (PA) | UL94 V-0 | |
 TE Connectivity AMP Connectors | General Purpose Industrial Lighting | All | Right Angle Through Hole | 11 | Shrouded - 4 Wall | 1 | Header | 4.2 A | Friction Lock | Tin | Board Lock Glow Wire Compliant | Circular | Board to Cable/Wire | Kinked Pin Solder | 0.299 " | 7.6 mm | Natural | 250 VAC | 0.126 " | 3.2 mm | Copper Alloy | Male Pin | -55 C | 105 ░C | 2.5 mm | 0.098 in | Nylon Polyamide (PA) | UL94 V-0 |
 TE Connectivity AMP Connectors | General Purpose Industrial Lighting | All | Right Angle Through Hole | 10 | Shrouded - 4 Wall | 1 | Header | 4.2 A | Friction Lock | Tin | Board Lock Glow Wire Compliant | Circular | Board to Cable/Wire | Kinked Pin Solder | 0.299 " | 7.6 mm | Natural | 250 VAC | 0.126 " | 3.2 mm | Copper Alloy | Male Pin | -55 C | 105 ░C | 2.5 mm | 0.098 in | Nylon Polyamide (PA) | UL94 V-0 |
