CFM25 Series
Manufacturer: Cincon Electronics Co. LTD
Beta
⌘K
SWITCHING POWER SUPPLIES AC-DC POWER SUPPLY, OPEN FRAME, 25 WATT, SINGLE OUTPUT, 36VDC OUTPUT, 0.7A, 87% EFFICIENCY, WAFER
| Part | Applications | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output 1 | Features | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Approval Agency | Voltage - Output 1 [custom] | Efficiency | Number of Outputs | Type | Voltage - Isolation | Power (Watts) | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | Household Appliances ITE (Commercial) | Chassis Mount | -30 °C | 70 °C | 264 VAC | 90 VAC | 700 mA | Universal Input | 0.91 in | 2.78 in | 23 mm | 70.5 mm | 1.1 in | 27.9 mm | CE cURus FCC NEMKO | 36 V | 87 % | 1 | Open Frame | 3000 V | 25 W | |
Cincon Electronics Co. LTD | Household Appliances ITE (Commercial) | Chassis Mount | -30 °C | 70 °C | 264 VAC | 90 VAC | Universal Input | 0.91 in | 2.78 in | 23 mm | 70.5 mm | 1.1 in | 27.9 mm | CE cURus FCC NEMKO | 87 % | 1 | Open Frame | 3000 V | 25 W | 48 V | ||
Cincon Electronics Co. LTD | Household Appliances ITE (Commercial) | Chassis Mount | -30 °C | 70 °C | 264 VAC | 90 VAC | 2.1 A | Universal Input | 0.91 in | 2.78 in | 23 mm | 70.5 mm | 1.1 in | 27.9 mm | CE cURus FCC NEMKO | 84 % | 1 | Open Frame | 3000 V | 25 W | 12 V |
