24_SMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
24_SMA-50-2-45/133_NH
| Part | Body Material | Dielectric Material | Center Contact Plating | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Mounting Feature | Cable Group | Frequency - Max [Max] | Connector Type | Shield Termination | Number of Ports | Connector Style | Impedance | Housing Color | Mounting Type | Contact Termination | Fastening Type | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | White Bronze | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RD-316 | 18 GHz | Female Socket Jack | Crimp | 1 | SMA | 50 Ohms | Silver | Panel Mount | Solder | Threaded | Beryllium Copper |
 Huber+Suhner, Inc. | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RG-141 | 18 GHz | Female Socket Jack | Solder | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper |
 Huber+Suhner, Inc. | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | White Bronze | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RG-405 (.086 Semi Rigid) | 18 GHz | Female Socket Jack | Solder | 1 | SMA | 50 Ohms | Silver | Panel Mount | Solder | Threaded | Beryllium Copper |
 Huber+Suhner, Inc. | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RG-405 (.086 Semi Rigid) | 18 GHz | Female Socket Jack | Solder | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper |
Huber+Suhner, Inc. | Bulkhead - Front Side Nut | RG-316 | 18 GHz | Female Socket Jack | Crimp | 1 | SMA | 50 Ohms | Silver | Panel Mount | Solder | Threaded | Beryllium Copper | |||||||
 Huber+Suhner, Inc. | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | 188 316 RG-174 | 18 GHz | Female Socket Jack | Crimp | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper |
 Huber+Suhner, Inc. | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RG-141 | 18 GHz | Female Socket Jack | Solder | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper |
 Huber+Suhner, Inc. | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | 18 GHz | Female Socket Jack | Solder | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper | |
 Huber+Suhner, Inc. | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | 500 | Bulkhead - Front Side Nut | RD-316 | 18 GHz | Female Socket Jack | Crimp | 1 | SMA | 50 Ohms | Gold | Panel Mount | Solder | Threaded | Beryllium Copper |
