180-M15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, HD15, PLUG, 180 M SERIES, 15 CONTACTS, DE, SOLDER
| Part | Contact Material | Dielectric Material | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Color | Wire Gauge [Min] | Wire Gauge [Max] | Contact Finish | Features | Contact Type | Mounting Type | Number of Positions | Number of Rows [custom] | Material Flammability Rating | Shell Material, Finish | Connector Style | Contact Finish Thickness | Connector Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Flange Feature | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 3 A 5 A | -55 C | 105 ░C | Black | 24 AWG | 28 AWG | Gold | Grounding Indents Shielded | Signal | Panel Mount | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Plug Male Pins | (DE E) High Density | 1 | Cable Side (4-40) | |
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 3 A 5 A | -55 C | 105 ░C | Black | 24 AWG | 28 AWG | Gold | Grounding Indents Shielded | Signal | Panel Mount | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Plug Male Pins | (DE E) High Density | 1 | Housing/Shell (Unthreaded) | |
 NorComp Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | 3 A 5 A | -55 C | 125 °C | Black | Gold | Board Lock Grounding Indents Shielded | Signal | Panel Mount Through Hole | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Plug Male Pins | (DE E) High Density | 1 | Board Side (4-40) Mating Side Female Screwlock (4-40) | Solder | ||
 NorComp Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | 3 A 5 A | -55 C | 125 °C | Black | Gold | Board Lock Shielded | Signal | Panel Mount Through Hole | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Receptacle Female Sockets | (DE E) High Density | 1 | Board Side (4-40) Mating Side Female Screwlock (4-40) | Solder | ||
NorComp Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | 3 A 5 A | -55 C | 125 °C | Black | Gold | Shielded | Signal | Panel Mount Through Hole | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Receptacle Female Sockets | (DE E) High Density | 1 | Board Side (4-40) | Solder | ||
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 3 A 5 A | -55 C | 105 ░C | Black | 24 AWG | 28 AWG | Gold | Grounding Indents Shielded | Signal | Panel Mount | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Plug Male Pins | (DE E) High Density | 1 | 4-40 Mating Side Female Screwlock | |
 NorComp Inc. | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | 3 A | -55 C | 125 °C | Black | 24 AWG | 28 AWG | Gold | Shielded | Signal | Panel Mount | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Receptacle Female Sockets | (DE E) High Density | 1 | 4-40 Mating Side Female Screwlock | |
 NorComp Inc. | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | 3 A | -55 C | 125 °C | Black | 24 AWG | 28 AWG | Gold | Shielded | Signal | Panel Mount | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Receptacle Female Sockets | (DE E) High Density | 1 | Housing/Shell (Unthreaded) | |
NorComp Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | 3 A 5 A | -55 C | 125 °C | Black | Gold | Grounding Indents Shielded | Signal | Panel Mount Through Hole | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Plug Male Pins | (DE E) High Density | 1 | Board Side (4-40) | Solder | ||
 NorComp Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | 3 A 5 A | -55 C | 125 °C | Black | Gold | Shielded | Signal | Panel Mount Through Hole | 15 | 3 | UL94 V-0 | Nickel Plated Steel | D-Sub High Density | Flash | Receptacle Female Sockets | (DE E) High Density | 1 | Housing/Shell (Unthreaded) | Solder |
