PX0709 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
CONN RCPT FMALE 2P NICKEL SCREW
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Mating | Contact Material | Primary Material | Connector Type | Voltage Rating | Fastening Type | Current Rating (Amps) | Shell Material | Insert Material [custom] | Insert Material [custom] | Termination | Mounting Type | Shielding | Color | Orientation | Number of Positions | Ingress Protection | Mounting Feature | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | -20 ░C | 70 °C | Nickel | Brass | Plastic | Receptacle Female Sockets | 277 VAC | Threaded | 12 Amps | Glass Filled Nylon Polyamide (PA) | Nylon | Polyamide (PA) | Screw | Panel Mount | Unshielded | Black | Keyed | 2 | IP68 IP69K | Bulkhead - Front Side Nut | UL94 HB |
BULGIN LIMITED | -20 ░C | 70 °C | Nickel | Brass | Plastic | Receptacle Female Sockets | 277 VAC | Threaded | 10 A | Glass Filled Nylon Polyamide (PA) | Nylon | Polyamide (PA) | Screw | Panel Mount | Unshielded | Black | Keyed | 4 | IP68 IP69K | Bulkhead - Front Side Nut | UL94 HB |
