PDRB-30 Series

Manufacturer: CUI Inc.

Catalog

DIN RAIL POWER SUPPLIES 24 VDC, 1.5 A, 36 W

Part	Efficiency	Power (Watts)	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Number of Outputs	Voltage - Isolation	Current - Output (Max) [Max]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Standard Number	Input Type	Voltage - Output 1	Applications	Approval Agency	Features	DC Voltage - Input (Max) [Max]	DC Voltage - Input (Min) [Min]
CUI Inc. PDRB-30-24	89 %	36 W	3.65 in	92.7 mm	1.38 in	2.28 "	35 mm	58 mm	1	4000 V	1.5 A	264 VAC	85 VAC	62368-1	AC or DC	24 V	ITE (Commercial)	CE cURus	Adjustable Output Universal Input	370 V	120 V
CUI Inc. PDRB-30-12	88 %	24 W	3.65 in	92.7 mm	1.38 in	2.28 "	35 mm	58 mm	1	4000 V	2 A	264 VAC	85 VAC	62368-1	AC or DC	12 V	ITE (Commercial)	CE cURus	Adjustable Output Universal Input	370 V	120 V
CUI Inc. PDRB-30-48	90 %	36 W	3.65 in	92.7 mm	1.38 in	2.28 "	35 mm	58 mm	1	4000 V	750 mA	264 VAC	85 VAC	62368-1	AC or DC	48 V	ITE (Commercial)	CE cURus	Adjustable Output Universal Input	370 V	120 V
CUI Inc. PDRB-30-5		15 W	3.65 in	92.7 mm	1.38 in	2.28 "	35 mm	58 mm	1	4000 V	3 A	264 VAC	85 VAC	62368-1	AC or DC	5 V	ITE (Commercial)	CE cURus	Adjustable Output Universal Input	370 V	120 V
