Power Inductors - SMD 330 UH 0.46A
Power Inductors - SMD 330 UH 0.46A
| Part | Current Rating (Amps) | DC Resistance (DCR) | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Type | Shielding | Tolerance | Inductance Frequency - Test | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Mounting Type | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Inductance | DC Resistance (DCR) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Murata Electronics | 270 mA | 4.9 Ohm | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 20 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 1 mH | |
 Murata Electronics | 1.05 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 20 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 68 µH | 360 mOhm | |
 Murata Electronics | 1.8 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 20 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 22 µH | 120 mOhm | |
 Murata Electronics | 8.7 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 30 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 0.28 µH | 8 mOhm | |
Murata Electronics | 390 mA | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 20 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 470 µH | 2.8 Ohm | |
Murata Electronics | 6.8 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 30 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 1 µH | 13 mOhm | |
Murata Electronics | 0.86 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 20 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 100 µH | 500 mOhm | |
Murata Electronics | 3.7 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 30 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 4.7 ÁH | 37 mOhm | |
Murata Electronics | 6.3 A | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 30 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 1.5 µH | 15 mOhm | |
Murata Electronics | 4.3 A | 29 mOhm | 125 °C | -40 C | Nonstandard | Wirewound | Shielded | 30 % | 10 kHz | 0.179 " | 4.55 mm | Surface Mount | 7.3 mm | 0.287 " | 0.287 in | 7.3 mm | 3.3 µH |
