G7L-2A Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
POWER RELAYS - DPST-NO,SCRW,TB ,
| Part | Features | Coil Type | Coil Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Switching Voltage | Coil Current | Contact Material | Termination Style | Coil Resistance | Mounting Type | Must Release Voltage | Coil Insulation | Contact Form | Release Time | Relay Type | Must Operate Voltage | Operate Time | Contact Rating (Current) | Load - Max Switching | Approval Agency | Switching Voltage [Max] | Seal Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | Test Button | Non Latching | 12 VDC | -25 °C | 60 °C | 250 VAC | 158 mA | Silver Tin Indium (AgSnIn) | Screw Terminal | 75 Ohms | Chassis Mount | 1.8 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 9 VDC | 30 ms | 25 A | ||||
Omron Electronics Inc-EMC Div | Non Latching | 48 VDC | -25 °C | 60 °C | 250 VAC | 40 mA | Silver Tin Indium (AgSnIn) | Quick Connect - 0.250" (6.3mm) | 1.22 kOhms | Chassis Mount | 7.2 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 36 VDC | 30 ms | 25 A | |||||
 Omron Electronics Inc-EMC Div | Test Button | Non Latching | 12 VDC | -25 °C | 60 °C | 250 VAC | 158 mA | Silver Alloy | Screw Terminal | 75 Ohms | Chassis Mount | 1.8 VDC | DPST-NO (2 Form A) | 30 ms | General Purpose | 9 VDC | 30 ms | 25 A | 6250 VA | CSA TUV UR | |||
 Omron Electronics Inc-EMC Div | Non Latching | 48 VDC | -25 °C | 60 °C | 250 VAC | 40 mA | Silver Alloy | Quick Connect - 0.250" (6.3mm) | 1.22 kOhms | Chassis Mount | 7.2 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 36 VDC | 30 ms | 25 A | 6250 VA | CSA TUV UR | |||
 Omron Electronics Inc-EMC Div | Test Button | Non Latching | 100 VDC | -25 °C | 60 °C | 250 VAC | 19 mA | Silver Alloy | Quick Connect - 0.250" (6.3mm) | 5.26 kOhms | Chassis Mount | 15 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 75 VDC | 30 ms | 25 A | 6250 VA | CSA TUV UR | ||
 Omron Electronics Inc-EMC Div | Non Latching | 24 VDC | -40 °C | 85 °C | 95.8 mA | Silver Alloy | PC Pin | 250 Ohms | Through Hole | 2.4 VDC | DPST-NO (2 Form A) | 30 ms | General Purpose | 18 VDC | 30 ms | 20 A | 20000 W | cURus VDE | 1000 VDC | Sealed - Flux Protection | |||
 Omron Electronics Inc-EMC Div | Non Latching | 48 VDC | -25 °C | 60 °C | 250 VAC | 40 mA | Silver Alloy | Quick Connect - 0.250" (6.3mm) | 1.22 kOhms | Chassis Mount | 7.2 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 36 VDC | 30 ms | 25 A | 6250 VA | CSA TUV UR | |||
 Omron Electronics Inc-EMC Div | Test Button | Non Latching | 50 VAC | -25 °C | 60 °C | 250 VAC | 34 mA | Silver Alloy | Quick Connect - 0.250" (6.3mm) | 1.31 kOhms | Chassis Mount | 7.5 VAC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 37.5 VAC | 30 ms | 25 A | 6250 VA | CSA TUV UR | ||
Omron Electronics Inc-EMC Div | Non Latching | 12 VAC/DC | -25 °C | 60 °C | 250 VAC | 142 mA | Silver Tin Indium (AgSnIn) | PC Pin | 75 Ohms | Through Hole | 1.8 VAC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 9 VAC | 30 ms | 20 A | |||||
Omron Electronics Inc-EMC Div | Non Latching | 12 VDC | -25 °C | 60 °C | 250 VAC | 158 mA | Silver Alloy | Screw Terminal | 75 Ohms | Chassis Mount | 1.8 VDC | Class B | DPST-NO (2 Form A) | 30 ms | General Purpose | 9 VDC | 30 ms | 25 A | 6250 VA | CSA TUV UR |
