F221V1IN Series

Catalog

FIT221V1IN WHITE 250 FT ROHS COMPLIANT: YES

Part	Shelf Life Start	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Shelf Life	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Color	Shrink Temperature	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Features	Recovered Wall Thickness	Recovered Wall Thickness	Type	Material	Length [x]	Length [x]
ALPHA WIRE F221V1IN WH003	Date of Manufacture	25.4 mm	1 in	144 Months	1	2	White	90 °C	76.2 m	250 ft	-55 C	135 °C	12.7 mm	0.5 "	Flame Retardant Fluid Resistant Heat Resistant	0.035 in	0.89 mm	Tubing Flexible	Polyolefin (PO) Irradiated
ALPHA WIRE F221V1IN RD105	Date of Manufacture	25.4 mm	1 in	144 Months	1	2	Red	90 °C			-55 C	135 °C	12.7 mm	0.5 "	Flame Retardant Fluid Resistant Heat Resistant	0.035 in	0.89 mm	Tubing Flexible	Polyolefin (PO) Irradiated	4 ft	1.22 m
ALPHA WIRE F221V1IN BK003	Date of Manufacture	25.4 mm	1 in	144 Months	1	2	Black	90 °C	76.2 m	250 ft	-55 C	135 °C	12.7 mm	0.5 "	Flame Retardant Fluid Resistant Heat Resistant UV Resistant	0.035 in	0.89 mm	Tubing Flexible	Polyolefin (PO) Irradiated
