N6L50 Series
Manufacturer: Amphenol Piher Sensing Systems
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
TRIMMER 4.7K OHM 0.1W PC PIN TOP
| Part | Tolerance | Power (Watts) | Power (Watts) Options | Resistance | Adjustment Type | Size / Dimension Shape | Size / Dimension Length | Size / Dimension Width | Termination Style | Mounting Type | Number of Turns | Temperature Coefficient | Resistive Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 4.7 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
 Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 10 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
 Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 1 MOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 20 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 1 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
 Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 10 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 300 Ohm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
 Amphenol Piher Sensing Systems | 30 % | 100 mW | 1/10W | 50 kOhm | Top Adjustment | Rectangular | 0.343 in | 0.252 in | PC Pins | Through Hole | 1 turns | 300 ppm/°C | Carbon |
