ELD107M Series
Manufacturer: KEMET
Beta
⌘K
CAP ALUM 100UF 20% 450V SNAP TH
| Part | Voltage - Rated | Applications | Mounting Type | Lead Spacing | Lead Spacing | Tolerance | Size / Dimension [diameter] | Size / Dimension [diameter] | Capacitance | Ripple Current @ Low Frequency | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Ripple Current @ High Frequency | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case | Polarization | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | 450 V | General Purpose | Through Hole | 0.394 in | 10 mm | 20 % | 0.984 " | 25 mm | 100 µF | 850 mA | 3.316 Ohm | 3000 Hrs | 1.19 A | 1.26 in | 32 mm | Radial Can - Snap-In | Polar | 105 ░C | -25 °C |
