Mini50 V0 Unsealed Header, Right-Angle, SMT, Single Row, 8 Circuits, Tin (Sn) Plating, Polarization Option B, Gray, Tape and Reel
Mini50 V0 Unsealed Header, Right-Angle, SMT, Single Row, 8 Circuits, Tin (Sn) Plating, Polarization Option B, Gray, Tape and Reel
Mini50 V0 Unsealed Header, Right-Angle, SMT, Single Row, 8 Circuits, Tin (Sn) Plating, Polarization Option B, Gray, Tape and Reel
| Part | Contact Length - Post | Contact Length - Post | Features | Number of Positions | Insulation Material | Fastening Type | Termination | Current Rating (Amps) | Contact Finish - Post | Pitch - Mating [x] | Pitch - Mating [x] | Contact Type | Style | Contact Shape | Mounting Type | Shrouding | Connector Type | Number of Positions Loaded | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Insulation Height | Insulation Height | Material Flammability Rating | Number of Rows | Insulation Color | Voltage Rating | Insulation Height [z] | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 1.04 mm | 0.041 in | Solder Retention | 8 | Syndiotactic Polystyrene (SPS) | Latch Holder | Solder | 4 A | Tin | 0.079 in | 2 mm | Male Pin | Board to Cable/Wire | Square | Through Hole Right Angle | Shrouded - 4 Wall | Header | All | 100 °C | -40 °C | Brass | 9.17 mm | 0.361 in | UL94 V-0 | 1 | Gray | 14 V | ||
Molex | Solder Retention | 8 | Syndiotactic Polystyrene (SPS) | Latch Holder | Solder | 1.5 A | Tin | 0.079 in | 2 mm | Male Pin | Board to Cable/Wire | Square | Surface Mount Right Angle | Shrouded - 4 Wall | Header | All | 100 °C | -40 °C | Brass | UL94 V-0 | 1 | Black | 14 V | 0.372 in | 9.44 mm |
