TMS-CT-50M Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

TMS-CT-50M-3/16-OUT-9 METER

Part	Shelf Life	Shelf Life Start	Spool Size [x]	Spool Size [x]	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Color	Length	Operating Temperature [Min]	Operating Temperature [Max]	Recovered Wall Thickness	Recovered Wall Thickness	Material	Features	Type	Shrinkage Ratio	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Inner Diameter - Supplied [diameter]	Length	Length	Inner Diameter - Recovered	Inner Diameter - Recovered
TE Connectivity AMP Connectors TMS-CT-50M-3/16-OUT-9	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.187 "	4.75 mm	White	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.062 in	1.57 mm
TE Connectivity AMP Connectors TMS-CT-50M-1/4-OUT-2L	144 Months	Date of Manufacture				0.25 "	Red		-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.083 in	2.11 mm	6.35 mm	50 m	164 ft
TE Connectivity AMP Connectors TMS-CT-50M-1/2-OUT-9	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.5 "	12.7 mm	White	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.61 mm	0.024 in	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1						4.22 mm	0.166 in
TE Connectivity AMP Connectors TMS-CT-50M-3/32-OUT-0	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.093 "	2.36 mm	Black	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.031 in	0.79 mm
TE Connectivity AMP Connectors TMS-CT-50M-1/4-OUT-0	48 Months 144 Months	Date of Manufacture	164 '	50 m		0.25 "	Black	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.083 in	2.11 mm	6.35 mm
TE Connectivity AMP Connectors TMS-CT-50M-1/8-OUT-0	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.125 in	3.18 mm	Black	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.042 "	1.07 mm
TE Connectivity AMP Connectors TMS-CT-50M-3/32-OUT-9	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.093 "	2.36 mm	White	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.031 in	0.79 mm
TE Connectivity AMP Connectors TMS-CT-50M-3/16-OUT-2	144 Months	Date of Manufacture	164 '	50 m	0.187 "	4.75 mm	Red	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.062 in	1.57 mm		50 m	164 ft
TE Connectivity AMP Connectors TMS-CT-50M-3/32-OUT-4	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.093 "	2.36 mm	Yellow	Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.031 in	0.79 mm
TE Connectivity AMP Connectors TMS-CT-50M-1/8-OUT-3	48 Months 144 Months	Date of Manufacture	164 '	50 m	0.125 in	3.18 mm		Enter Number of Meters in Order Quantity	-55 C	135 °C	0.58 mm	0.023 "	Polyolefin (PO) Irradiated	Flame Retardant Fluid Resistant	Tubing Flexible	3 to 1	0.042 "	1.07 mm		50 m	164 ft
