PRPC002 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HEADER R/A 2POS 2.54MM
| Part | Contact Finish Thickness - Post | Contact Length - Mating | Contact Length - Mating | Insulation Height | Insulation Height | Contact Shape | Contact Length - Post | Contact Length - Post | Contact Finish Thickness - Mating | Number of Positions | Number of Rows | Contact Material | Connector Type | Number of Positions Loaded | Current Rating (Amps) | Material Flammability Rating | Termination | Insulation Color | Contact Type | Contact Finish - Mating | Shrouding | Insulation Material | Style | Mounting Type | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Overall Contact Length | Overall Contact Length | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Number of Rows [custom] | Overall Contact Length [x] | Overall Contact Length [x] | Overall Contact Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.098 " | 2.5 mm | Square | 3.05 mm | 0.12 in | Flash | 2 | 1 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Right Angle Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | ||||||||
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.098 " | 2.5 mm | Square | 3.05 mm | 0.12 in | Flash | 4 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.448 in | 11.39 mm | 0.1 in | 2.54 mm | 2 | ||||
 Sullins Connector Solutions | Flash | 0.318 in | 8.08 mm | 0.098 " | 2.5 mm | Square | 3.05 mm | 0.12 in | Flash | 2 | 1 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 13.63 mm | 0.537 in | ||||||
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.098 " | 2.5 mm | Square | 8.13 mm | 0.32 in | Flash | 2 | 1 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Right Angle Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | ||||||||
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.098 " | 2.5 mm | Square | 10.67 mm | 0.42 in | Flash | 2 | 1 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.748 in | 19.01 mm | ||||||
 Sullins Connector Solutions | Flash | 0.318 in | 8.08 mm | 0.098 " | 2.5 mm | Square | 5.58 mm | 0.22 in | Flash | 4 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.637 in | 0.1 in | 2.54 mm | 2 | 16.17 mm | ||||
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.098 " | 2.5 mm | Square | 5.84 mm | 0.23 " | Flash | 4 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.558 in | 14.18 mm | 0.1 in | 2.54 mm | 2 | ||||
 Sullins Connector Solutions | Flash | 0.23 in | 5.84 mm | 0.197 " | 5 mm | Square | 3.05 mm | 0.12 in | Flash | 4 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Right Angle Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.1 in | 2.54 mm | 2 | ||||||
 Sullins Connector Solutions | Flash | 0.318 in | 8.08 mm | 0.098 " | 2.5 mm | Square | 3.05 mm | 0.12 in | Flash | 2 | 1 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Right Angle Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | ||||||||
 Sullins Connector Solutions | Flash | 0.318 in | 8.08 mm | 0.098 " | 2.5 mm | Square | 3.05 mm | 0.12 in | Flash | 4 | Brass | Header Breakaway | All | 3 A | UL94 V-0 | Solder | Black | Male Pin | Gold | Unshrouded | Polybutylene Terephthalate (PBT) | Board to Board Cable | Through Hole | Gold | 0.1 " | 2.54 mm | -40 C | 105 ░C | Push-Pull | 0.1 in | 2.54 mm | 2 | 13.63 mm | 0.537 in |
