629-M50 Series
Manufacturer: EDAC Inc.
Beta
⌘K
629M SERIES RIGHT ANGLE D-SUB PL
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Dielectric Material | Backset Spacing | Backset Spacing | Shell Material, Finish | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Type | Features | Termination | Number of Positions | Material Flammability Rating | Flange Feature | Contact Type | Mounting Type | Contact Finish | Current Rating (Amps) | Connector Style | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | Nickel Plated Steel | 3 | 30 Áin | 0.76 Ám | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | 4-40 | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 15 µin | 0.38 µm | 5 | D DD | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | 4-40 | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 15 µin | 0.38 µm | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | 4-40 | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | Nickel Plated Steel | 3 | 30 Áin | 0.76 Ám | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | Housing/Shell | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | 4-40 | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | Nickel Plated Steel | 3 | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | 4-40 | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | Housing/Shell | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | 4-40 | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 15 µin | 0.38 µm | 5 | D DD | Plug Male Pins | Grounding Indents Shielded | Solder | 50 | UL94 V-0 | Housing/Shell (Unthreaded) | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | Nickel Plated Steel | 3 | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | Housing/Shell | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | 4-40 | Flash | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 30 Áin | 0.76 Ám | 5 | D DD | Plug Male Pins | Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | Board Side (4-40) | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | 9.4 mm | 0.37 in | 3 | 30 Áin | 0.76 Ám | 5 | D DD | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | 50 | UL94 V-0 | 4-40 | Signal | Right Angle Through Hole | Gold | 5 A | Combo D-Sub |
