391-018 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 18POS 0.100
| Part | Termination Rows | Material - Insulation | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Card Type | Number of Positions | Contact Material | Number of Rows | Number of Positions/Bay/Row [custom] | Card Thickness [Max] | Card Thickness [Min] | Color | Termination | Read Out | Flange Feature | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Contact Finish | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Single Edge | 18 | Copper Alloy | 1 | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Single | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | ||||||
 EDAC Inc. | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Dual Edge | 18 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Dual | Flush Mount Top Opening Unthreaded | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 2 | 0.156 " | 3.96 mm | 2 | 9 | Card Extender | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Single Edge | 18 | Copper Alloy | 1 | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Single | Floating Bobbin Flush Mount | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Dual Edge | 18 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Dual | Floating Bobbin Flush Mount | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 2 | 0.116 " | 2.95 mm | 2 | 9 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Single Edge | 18 | Copper Alloy | 1 | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Single | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Single Edge | 18 | Copper Alloy | 1 | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Single | Flush Mount Top Opening Unthreaded | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Dual Edge | 18 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Dual | Flush Mount Top Opening Unthreaded | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 2 | 0.128 " | 3.25 mm | 2 | 9 | Card Extender | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Single Edge | 18 | Copper Alloy | 1 | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Single | Flush Mount Top Opening Unthreaded | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Dual Edge | 18 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder | Dual | Flush Mount Top Opening Unthreaded | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 2 | 0.156 " | 3.96 mm | 2 | 9 | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | -40 C | 105 ░C | Semi Bellows | Non Specified - Dual Edge | 18 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Solder Eyelet(s) | Dual | Floating Bobbin Flush Mount | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Gold | 2 | 0.116 " | 2.95 mm | 2 | 9 | Card Extender |
