LED Power Supplies 6W 230Vin 2-12Vout 500mA
LED Power Supplies 6W 230Vin 2-12Vout 500mA
| Part | Topology | Current - Output (Max) [Max] | Voltage - Output [Max] | Voltage - Output [Min] | Voltage - Isolation | Ratings | Voltage - Input (Max) [Max] | Number of Outputs | Efficiency | Type | Features | Termination Style | Power (Watts) | Approval Agency | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | AC DC Converter | 500 mA | 12 V | 2 V | 3750 VDC | IP20 | 264 VAC | 1 | 75 % | Constant Current | OTP OVP SCP | Terminal Block | 6 W | CE cETLus ENEC PSE RCM | 11 mm | 3.86 " | 46 mm | 0.43 in | 98 mm | 1.81 in | -20 ░C | 50 °C | 198 VAC |
 Recom Power | AC DC Converter | 700 mA | 9 V | 2 V | 3750 VDC | IP20 | 264 VAC | 1 | 74 % | Constant Current | OTP OVP SCP | Terminal Block | 6 W | CE cETLus ENEC PSE RCM | 11 mm | 3.86 " | 46 mm | 0.43 in | 98 mm | 1.81 in | -20 ░C | 50 °C | 198 VAC |
Recom Power | AC DC Converter | 350 mA | 18 V | 2 V | 3750 VDC | IP20 | 264 VAC | 1 | 77 % | Constant Current | OTP OVP SCP | Terminal Block | 6 W | CE cETLus ENEC PSE RCM | 11 mm | 3.86 " | 46 mm | 0.43 in | 98 mm | 1.81 in | -20 ░C | 50 °C | 198 VAC |
