VO305 Series

Catalog

OPTOISOLATOR 5.3KV TRIAC 6DIP

Part	Package / Case	Package / Case	Package / Case	Current - DC Forward (If) (Max) [Max]	Current - On State (It (RMS)) (Max) [Max]	Static dV/dt (Min) [Min]	Mounting Type	Current - LED Trigger (Ift) (Max) [Max]	Output Type	Approval Agency	Voltage - Isolation [custom]	Voltage - Off State	Supplier Device Package	Current - Hold (Ih)	Operating Temperature [Max]	Operating Temperature [Min]	Number of Channels [custom]
Vishay Semiconductor Opto Division VO3052-X016	6-DIP	10.16 mm	0.4 in	60 mA	100 mA	1.5 kV/µs	Through Hole	10 mA	Triac	cUR UR VDE	5300 Vrms	600 V	6-DIP	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3052-X007T	6-SMD			60 mA	100 mA	1.5 kV/µs	Surface Mount	10 mA	Triac	cUR UR	5300 Vrms	600 V	6-SMD	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3053-X009T	6-SMD Gull Wing			60 mA	100 mA	1.5 kV/µs	Surface Mount	5 mA	Triac	cUR UR	5300 Vrms	600 V	6-SMD	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3053-X007T	6-SMD Gull Wing			60 mA	100 mA	1.5 kV/µs	Surface Mount	5 mA	Triac	cUR UR	5300 Vrms	600 V	6-SMD	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3052	6-DIP (0.300" 7.62mm)			60 mA	100 mA	1.5 kV/µs	Through Hole	10 mA	Triac	cUR UR	5300 Vrms	600 V	6-DIP	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3053	6-DIP (0.300" 7.62mm)			60 mA	100 mA	1.5 kV/µs	Through Hole	5 mA	Triac	cUR UR	5300 Vrms	600 V	6-DIP	200 µA	100 °C	-55 C	1
Vishay Semiconductor Opto Division VO3053-X006	6-DIP	10.16 mm	0.4 in	60 mA	100 mA	1.5 kV/µs	Through Hole	5 mA	Triac	cUR UR	5300 Vrms	600 V	6-DIP	200 µA	100 °C	-55 C	1
