PT78NR1 Series
Manufacturer: Texas Instruments
Beta
⌘K
MODULE DC-DC 1-OUT -5V 1A 5W 3-PIN(3+2TAB) SIP MODULE
| Part | Current - Output (Max) [Max] | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Efficiency | Mounting Type | Voltage - Output 1 | Type | Number of Outputs | Features | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 1 A | 25 V | 7 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Through Hole Right Angle | -5 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SIP Module |
 Texas Instruments | 1 A | 25 V | 7 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Surface Mount | -5 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SMD Module |
 Texas Instruments | 1 A | 25 V | 7 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Through Hole Right Angle | -3 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SIP Module |
Texas Instruments | 1 A | 25 V | 7 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Through Hole Right Angle | -5.2 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SIP Module |
Texas Instruments | 400 mA | 18 V | 7 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Through Hole Right Angle | -12 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SIP Module |
Texas Instruments | 300 mA | 15 V | 7 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Surface Mount | -15 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SMD Module |
 Texas Instruments | 1 A | 25 V | 7 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | 85 °C | -40 °C | ITE (Commercial) | 75 % | Through Hole | -5.2 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SIP Module |
Texas Instruments | 800 mA | 21 V | 7 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Surface Mount | -6 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SMD Module |
Texas Instruments | 1 A | 25 V | 7 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Surface Mount | -5.2 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SMD Module |
Texas Instruments | 550 mA | 21 V | 7 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 85 °C | -40 °C | ITE (Commercial) | 75 % | Surface Mount | -9 V | Non-Isolated PoL Module | 1 | OTP SCP | 3-SMD Module |
