3RT1065 Series
Manufacturer: Siemens
Beta
⌘K
CONTACTOR. 132 KW / 400 V /AC-3
| Part | Operate Time | Release Time | Coil Power | Switching Voltage [Max] | Mounting Type | Contact Form | Coil Voltage [Max] | Coil Voltage [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Rating (Current) | Termination Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Siemens | 80 ms | 100 ms | 580 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 277 VAC | 200 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
 Siemens | 95 ms | 80 ms | 650 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 277 VAC | 240 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
Siemens | 95 ms | 80 ms | 650 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 480 VAC/DC | 440 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
Siemens | 95 ms | 80 ms | 650 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 220 VAC/DC | 200 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
 Siemens | 95 ms | 80 ms | 650 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 26 VAC/DC | 23 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
 Siemens | 95 ms | 80 ms | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts | |||
 Siemens | 75 ms | 130 ms | 580 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 127 VAC/DC | 96 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
 Siemens | 80 ms | 100 ms | 580 W | 1000 VAC | Chassis Mount DIN Rail | 3PST-NO (3 Form A) | 127 VAC/DC | 96 VAC/DC | -25 °C | 60 °C | 265 A | Screw Terminal | Auxiliary Contacts |
