B72214P Series

Catalog

14MM, 420VAC, 10%, MP ADVANCED

Part	Number of Circuits	Varistor Voltage (Typ)	Maximum AC Volts [Max]	Maximum DC Volts [Max]	Package / Case	Energy	Varistor Voltage (Max) [Max]	Mounting Type	Current - Surge	Varistor Voltage (Min) [Min]	Capacitance @ Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Varistor Voltage (Max)
EPCOS - TDK Electronics B72214P2421K351	1	680 V	420 V	560 V	Disc 14mm	190 J	748 V	Through Hole	6000 A	612 V	355 pF	-40 C	105 ░C
EPCOS - TDK Electronics B72214P2141K101	1	220 V	140 V	180 V	Disc 14mm	65 J		Through Hole	6000 A	198 V	1000 pF	-40 °C	105 °C	242 V
EPCOS - TDK Electronics B72214P2321K101	1	510 V	320 V	420 V	Disc 14mm	150 J	561 V	Through Hole	6000 A	459 V	445 pF	-40 °C	105 °C
EPCOS - TDK Electronics B72214P2271K551	1	430 V	275 V	350 V	Disc 14mm	130 J		Through Hole	6000 A	387 V	530 pF	-40 C	105 ░C	473 V
EPCOS - TDK Electronics B72214P2301K392	1	470 V	300 V	385 V	Disc 14mm	140 J	517 V	Through Hole	6000 A	423 V	485 pF	-40 C	105 ░C
EPCOS - TDK Electronics B72214P2151K101	1	240 V	150 V	200 V	Disc 14mm	70 J	264 V	Through Hole	6000 A	216 V	1000 pF	-40 °C	105 °C
EPCOS - TDK Electronics B72214P2211K101	1	330 V	210 V	270 V	Disc 14mm	95 J	363 V	Through Hole	6000 A	297 V	690 pF	-40 °C	105 °C
EPCOS - TDK Electronics B72214P2271K101	1	430 V	275 V	350 V	Disc 14mm	130 J		Through Hole	6000 A	387 V	530 pF	-40 °C	105 °C	473 V
