SML-012 Series

Chip LED with reflector, Yellow-green Chip LED

Manufacturer: Rohm Semiconductor

Catalog

Chip LED with reflector, Yellow-green Chip LED

Description

AI

SML-01 series is a reflector type surface mount LED.

Catalog

Chip LED with reflector, Yellow-green Chip LED

Part	Supplier Device Package	Supplier Device Package	Configuration	Wavelength - Dominant	Size / Dimension [x]	Size / Dimension [y]	Voltage - Forward (Vf) (Typ)	Lens Color	Height (Max) [z]	Package / Case	Lens Transparency	Millicandela Rating	Lens Style	Mounting Type	Current - Test	Lens Size [y]	Lens Size [x]	Color	Supplier Device Package
Rohm Semiconductor SML-012DTT86A	3020	1208	Standard	605 nm	3 mm	2 mm	2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	100 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm
Rohm Semiconductor SML-012D8TT86	3020	1208	Standard	605 nm	3 mm	2 mm	2.2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	160 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm
Rohm Semiconductor SML-012DTT86	3020	1208	Standard	605 nm	3 mm	2 mm	2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	100 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm
Rohm Semiconductor SML-012VTT86A	3020	1208	Standard	630 nm	3 mm	2 mm	2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	71 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm	Red
Rohm Semiconductor SML-012P8TT86	3020	1208	Standard	560 nm	3 mm	2 mm	2.2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	6.3 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm	Green
Rohm Semiconductor SML-012M8TT86	3020	1208	Standard	572 nm	3 mm	2 mm	2.2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	40 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm	Green
Rohm Semiconductor SML-012YTT86				590 nm	3 mm	2 mm	2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	100 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm	Yellow	1208
Rohm Semiconductor SML-012V8TT86	3020	1208	Standard	630 nm	3 mm	2 mm	2.2 V	Colorless	1.5 mm	1208 (3020 Metric)	Clear	63 mcd	Rectangle with Flat Top	Surface Mount	20 mA	1.6 mm	2.3 mm	Red
