General Purpose Relays V23148-A0005-C101
General Purpose Relays V23148-A0005-C101
| Part | Coil Resistance | Must Operate Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Coil Type | Release Time | Contact Material | Termination Style | Relay Type | Coil Current | Must Release Voltage | Switching Voltage [Max] | Contact Form | Contact Rating (Current) | Mounting Type | Operate Time | Coil Voltage | Load - Max Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 56 Ohms | 3.5 VDC | -25 °C | 70 °C | Non Latching | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 89.3 mA | 0.5 VDC | 400 VAC | SPDT (1 Form C) | 7 A | Through Hole | 5 ms | 5 VDC | 2800 VA |
TE Connectivity AMP Connectors | 1280 Ohms | 16.8 VDC | -25 °C | 70 °C | Non Latching | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 18.8 mA | 2.4 VDC | 400 VAC | SPST-NC (1 Form B) | 7 A | Through Hole | 5 ms | 24 VDC | 2800 VA |
TE Connectivity AMP Connectors | -25 °C | 70 °C | Latching Single Coil | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 400 VAC | SPDT (1 Form C) | 7 A | Through Hole | 5 ms | 2800 VA | |||||
 TE Connectivity AMP Connectors | 1280 Ohms | 16.8 VDC | -25 °C | 70 °C | Non Latching | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 16.7 mA | 2.4 VDC | 400 VAC | SPDT (1 Form C) | 7 A | Through Hole | 5 ms | 24 VDC | 2800 VA |
 TE Connectivity AMP Connectors | 119 Ohms | 9.4 VDC | -25 °C | 70 °C | Latching Single Coil | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 16.7 mA | 400 VAC | SPDT (1 Form C) | 7 A | Through Hole | 5 ms | 12 VDC | 2800 VA | |
TE Connectivity AMP Connectors | 320 Ohms | 8.4 VDC | -25 °C | 70 °C | Non Latching | 3 ms | Silver Nickel (AgNi) | PC Pin | General Purpose | 0.0375 A | 1.2 VDC | 400 VAC | SPST-NC (1 Form B) | 7 A | Through Hole | 5 ms | 12 VDC | 2800 VA |
