PQQ10W Series
Manufacturer: CUI Inc.
Beta
⌘K
DC-DC ISOLATED, 10 W, 9~36 VDC I
| Part | Approval Agency | Applications | Type | Voltage - Input (Min) [Min] | Efficiency | Features | Mounting Type | Package / Case | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Output 1 | Voltage - Input (Max) [Max] | Number of Outputs | Current - Output (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | CE | ITE (Commercial) | Isolated Module | 9 V | 88 % | Remote On/Off | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 15 V | 36 V | 1 | 667 mA | -40 °C | 85 °C | 10 W | 1.5 kV |
CUI Inc. | CE | ITE (Commercial) | Isolated Module | 9 V | 88 % | Remote On/Off | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 12 V | 36 V | 1 | 833 mA | -40 °C | 85 °C | 10 W | 1.5 kV |
CUI Inc. | CE | ITE (Commercial) | Isolated Module | 9 V | 88 % | Remote On/Off | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 5 V | 36 V | 1 | 2 A | -40 °C | 85 °C | 10 W | 1.5 kV |
 CUI Inc. | CE | ITE (Commercial) | Isolated Module | 9 V | 88 % | Remote On/Off | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 24 V | 36 V | 1 | -40 °C | 85 °C | 10 W | 1.5 kV | |
CUI Inc. | CE | ITE (Commercial) | Isolated Module | 9 V | 88 % | Remote On/Off | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 9 V | 36 V | 1 | 1.111 A | -40 °C | 85 °C | 10 W | 1.5 kV |
