2307815 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

5P,2MM,BB,REC,SRVT,SMD,AU.76,TR,

Part	Insulation Color	Contact Finish - Post	Insulation Height	Insulation Height	Features	Insulation Material	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Current Rating (Amps)	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Pitch - Mating [x]	Pitch - Mating [x]	Fastening Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating	Contact Material	Mounting Type	Material Flammability Rating	Termination	Contact Type	Contact Finish - Mating	Connector Type	Number of Positions
TE Connectivity Raychem Cable Protection 2307815-5	Black	Tin	0.177 in	4.5 mm	Pick and Place	Liquid Crystal Polymer (LCP)	Square	3 µm	118.1 µin	2 A	1	30 Áin	0.76 Ám	All	0.079 in	2 mm	Push-Pull	125 °C	-40 °C	125 VDC	Phosphor Bronze	Surface Mount	UL94 V-0	Solder	Female Socket	Gold	Receptacle Bottom or Top Entry
TE Connectivity Raychem Cable Protection 2307815-8	Black	Tin	0.177 in	4.5 mm	Pick and Place	Liquid Crystal Polymer (LCP)	Square	3 µm	118.1 µin	2 A	1	30 Áin	0.76 Ám	All	0.079 in	2 mm	Push-Pull	125 °C	-40 °C	125 VDC	Phosphor Bronze	Surface Mount	UL94 V-0	Solder	Female Socket	Gold	Receptacle Bottom or Top Entry	8
TE Connectivity Raychem Cable Protection 2307815-2	Black	Tin	0.177 in	4.5 mm	Pick and Place	Liquid Crystal Polymer (LCP)	Square	3 µm	118.1 µin	2 A	1	30 Áin	0.76 Ám	All	0.079 in	2 mm	Push-Pull	125 °C	-40 °C	125 VDC	Phosphor Bronze	Surface Mount	UL94 V-0	Solder	Female Socket	Gold	Receptacle Bottom or Top Entry	2
TE Connectivity Raychem Cable Protection 2307815-3	Black	Tin	0.177 in	4.5 mm	Pick and Place	Liquid Crystal Polymer (LCP)	Square	3 µm	118.1 µin	2 A	1	30 Áin	0.76 Ám	All	0.079 in	2 mm	Push-Pull	125 °C	-40 °C	125 VDC	Phosphor Bronze	Surface Mount	UL94 V-0	Solder	Female Socket	Gold	Receptacle Bottom or Top Entry
TE Connectivity Raychem Cable Protection 1-2307815-0	Black	Tin	0.177 in	4.5 mm	Pick and Place	Liquid Crystal Polymer (LCP)	Square	3 µm	118.1 µin	2 A	1	30 Áin	0.76 Ám	All	0.079 in	2 mm	Push-Pull	125 °C	-40 °C	125 VDC	Phosphor Bronze	Surface Mount	UL94 V-0	Solder	Female Socket	Gold	Receptacle Bottom or Top Entry	10
