CV275 Series

Catalog

CV 275VRMS 7MM BULK L1

Part	Varistor Voltage (Typ)	Operating Temperature [Max]	Operating Temperature [Min]	Capacitance @ Frequency	Maximum AC Volts [Max]	Varistor Voltage (Min) [Min]	Number of Circuits	Current - Surge	Mounting Type	Energy	Package / Case	Maximum DC Volts [Max]	Varistor Voltage (Max)	Package / Case
Bourns Inc. CV275K7BL1	430 V	85 C	-40 ¯C	1 kHz 160 pF	275 V	387 V	1	1200 A	Through Hole	35 J	Disc 7mm	350 V	473 V
Bourns Inc. CV275K14RL1	430 V	85 C	-40 ¯C	530 pF	275 V	387 V	1	4.5 kA	Through Hole	150 J	Disc 14mm	350 V	473 V
Bourns Inc. CV275K5BL1	430 V	85 C	-40 ¯C	1 kHz 70 pF	275 V	387 V	1	400 A	Through Hole	16 J	Disc 5mm	350 V	473 V
Bourns Inc. CV275K10BL1	430 V	85 C	-40 ¯C	1 kHz 300 pF	275 V	387 V	1	2.5 kA	Through Hole	78 J	Disc 10mm	350 V	473 V
Bourns Inc. CV275K20BL1	430 V	85 C	-40 ¯C	900 pF	275 V	387 V	1		Through Hole	304 J	Disc	350 V	473 V	20 mm
Bourns Inc. CV275K7RL1	430 V	85 C	-40 ¯C	1 kHz 160 pF	275 V	387 V	1	1200 A	Through Hole	35 J	Disc 7mm	350 V	473 V
Bourns Inc. CV275K14BL1	430 V	85 C	-40 ¯C	530 pF	275 V	387 V	1	4.5 kA	Through Hole	150 J	Disc 14mm	350 V	473 V
Bourns Inc. CV275K10RL1	430 V	85 C	-40 ¯C	1 kHz 300 pF	275 V	387 V	1	2.5 kA	Through Hole	78 J	Disc 10mm	350 V	473 V
