SRCN2A25 Series
Manufacturer: JAE Electronics
Beta
⌘K
CONN RCPT MALE 16P SOLDER CUP
| Part | Applications | Color | Shell Finish | Connector Type | Primary Material | Insert Material | Voltage Rating | Shell Material | Material Flammability Rating | Contact Material | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Number of Positions | Fastening Type | Current Rating (Amps) | Contact Finish - Mating | Mounting Feature | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
JAE Electronics | Communication Systems Measurement Telecommunications Test Equipment | Silver | Nickel | Receptacle Male Pins | Metal | Plastic | 250 VAC 350 VDC | Aluminum Alloy | UL94 V-0 | Copper Alloy | 25 | 16 | 85 °C | -25 °C | N (Normal) | 16 | Threaded | 10 A | Silver | Flange | Panel Mount |
 JAE Electronics | Communication Systems Measurement Telecommunications Test Equipment | Silver | Nickel | Receptacle Female Sockets | Metal | Plastic | 250 VAC 350 VDC | Aluminum Alloy | UL94 V-0 | Copper Alloy | 24 | 25 | 85 °C | -25 °C | N (Normal) | 24 | Threaded | 5 A | Silver | Flange | Panel Mount |
 JAE Electronics | Communication Systems Measurement Telecommunications Test Equipment | Silver | Nickel | Receptacle Male Pins | Metal | Plastic | 250 VAC 350 VDC | Aluminum Alloy | UL94 V-0 | Copper Alloy | 24 | 25 | 85 °C | -25 °C | N (Normal) | 24 | Threaded | 5 A | Silver | Flange | Panel Mount |
 JAE Electronics | Communication Systems Measurement Telecommunications Test Equipment | Silver | Nickel | Receptacle Female Sockets | Metal | Plastic | 250 VAC 350 VDC | Aluminum Alloy | UL94 V-0 | Copper Alloy | 25 | 16 | 85 °C | -25 °C | N (Normal) | 16 | Threaded | 10 A | Silver | Flange | Panel Mount |
