SRP0420 Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTORS - SMD IND,4.4X4.1X2MM,6.8UH+/-10%,2.6A,SHD,SMD
| Part | Inductance | Inductance Frequency - Test | Frequency - Self Resonant | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Tolerance | Package / Case | Mounting Type | Current - Saturation (Isat) | Current Rating (Amps) | Material - Core | Shielding | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | DC Resistance (DCR) [Max] | Q @ Freq | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 6.8 µH | 100 kHz | 20 MHz | 0.079 in | 2 mm | 10 % | Nonstandard | Surface Mount | 3.8 A | 2.6 A | Metal | Shielded | 4.1 mm | 0.173 in | 4.4 mm | 0.161 in | 117 mOhm | 27 | 125 °C | -40 C |
