F221V3/16 Series

Catalog

FIT221V3/16 WHITE 25X4 FT ROHS COMPLIANT: YES

Part	Shelf Life Start	Length [x]	Length [x]	Features	Shrink Temperature	Type	Recovered Wall Thickness	Recovered Wall Thickness	Material	Operating Temperature [Min]	Operating Temperature [Max]	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Shelf Life	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Color	Length	Length	Length
ALPHA WIRE F221V3/16 WH103	Date of Manufacture	4 ft	1.22 m	Flame Retardant Fluid Resistant Heat Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	White
ALPHA WIRE F221V3/16 YL002	Date of Manufacture			Flame Retardant Fluid Resistant Heat Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	Yellow	152.4 m	500 ft
ALPHA WIRE F221V3/16 WH002	Date of Manufacture			Flame Retardant Fluid Resistant Heat Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	White	152.4 m	500 ft
ALPHA WIRE F221V3/16 BK002	Date of Manufacture			Flame Retardant Fluid Resistant Heat Resistant UV Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	Black	7.6 m 15.2 m 152.4 m 152.4 mm	0.5 ' 25 ft 50 ft 500 ft	6 "
ALPHA WIRE F221V3/16 YL103	Date of Manufacture	4 ft	1.22 m	Flame Retardant Fluid Resistant Heat Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	Yellow
ALPHA WIRE F221V3/16 BL103	Date of Manufacture	4 ft	1.22 m	Flame Retardant Fluid Resistant Heat Resistant	90 °C	Tubing Flexible	0.51 mm	0.02 in	Polyolefin (PO) Irradiated	-55 C	135 °C	0.187 "	4.75 mm	1	2	144 Months	2.36 mm	0.093 in	Blue
