1052 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN SMA RCPT R/A 50 OHM SOLDER
| Part | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Voltage Rating | Center Contact Plating | Body Material | Mating Cycles | Mounting Type | Housing Color | Impedance | Mounting Feature | Shield Termination | Features | Center Contact Material | Frequency - Max [Max] | Contact Termination | Number of Ports | Fastening Type | Connector Type | Connector Style | Includes | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Gold | -65 ░C | 125 °C | Polytetrafluoroethylene (PTFE) | 335 V | Gold | Stainless Steel | 500 | Panel Mount Right Angle | Gold | 50 Ohms | Flange | Solder | Extended Insulation | Beryllium Copper | 18 GHz | Solder | 1 | Threaded | Receptacle Female Socket | SMA | ||
TE Connectivity AMP Connectors | Gold | -55 C | 105 ░C | Polytetrafluoroethylene (PTFE) | 190 V | Gold | Stainless Steel | 500 | Panel Mount | Gold | 50 Ohms | Flange | Solder | Beryllium Copper | 18 GHz | Solder Tab | 1 | Threaded | Receptacle Female Socket | SMA | |||
 TE Connectivity AMP Connectors | -65 ░C | 105 ░C | Polytetrafluoroethylene (PTFE) | 335 V | Gold | Stainless Steel | 500 | Panel Mount | Silver | 50 Ohms | Flange | Solder | Beryllium Copper | 18 GHz | Solder | 1 | Threaded | Receptacle Female Socket | SMA | ||||
TE Connectivity AMP Connectors | |||||||||||||||||||||||
TE Connectivity AMP Connectors | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | 335 V | Gold | Stainless Steel | 500 | Free Hanging (In-Line) Right Angle | Silver | 50 Ohms | Crimp | Beryllium Copper | 12.4 GHz | Crimp Solder | 1 | Threaded | Plug Male Pin | SMA | 1 Connector 1 Contact 1 Ferrule | RG-142 | |||
 TE Connectivity AMP Connectors | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | 335 V | Gold | Stainless Steel | 500 | Panel Mount | Silver | 50 Ohms | Flange | Screw | Field Replaceable For Hermetically Sealed Pin | Beryllium Copper | 18 GHz | Compression | 1 | Threaded | Receptacle Female Socket | SMA | |||
 TE Connectivity AMP Connectors | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | 500 | Panel Mount | Silver | 50 Ohms | Flange | Screw | EMI/RFI Gasket Field Replaceable For Hermetically Sealed Pin | Beryllium Copper | 18 GHz | Compression | 1 | Threaded | Receptacle Female Socket | SMA | 1 Connector 1 Gasket | |||
TE Connectivity AMP Connectors | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | 335 V | Gold | Stainless Steel | 500 | Panel Mount | Silver | 50 Ohms | Flange | Screw | Field Replaceable For Hermetically Sealed Pin | Beryllium Copper | 18 GHz | Compression | 1 | Threaded | Receptacle Female Socket | SMA | |||
TE Connectivity AMP Connectors | |||||||||||||||||||||||
TE Connectivity AMP Connectors | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | 500 | Panel Mount | Silver | 50 Ohms | Flange | Solder | Beryllium Copper | 18 GHz | Solder Tab | 1 | Threaded | Receptacle Female Socket | SMA |
