CGS TLR Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

SMD CURRENT SENSE RESISTORS, TLR SERIES, 0.0015 OHM, 1 W, - 1%, 2512 [6432 METRIC]

Part	Resistance	Power (Watts)	Supplier Device Package	Features	Temperature Coefficient	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Number of Terminations [custom]	Package / Case	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Supplier Device Package	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]
TE Connectivity AMP Connectors TLR3A10DR0015FTDG	1.5 mOhms	1 W	2512	Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2	6332 Metric	2512	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR3A20WR006FTDG	6 mOhms	2 W	2512	Current Sense	75 ppm/°C	1 %	170 °C	-55 C	2	6332 Metric	2512 2512 (6432 Metric)	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR3A20DR00075FTDG	750 µOhms	2 W	2512	Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2	6332 Metric	2512	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR3A10DR0005FTDG	0.5 mOhms	1 W	2512	Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2	6332 Metric	2512	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR3A20KR003FTDG	3 mOhms	2 W	2512	Current Sense	150 ppm/°C	1 %	170 °C	-55 C	2	6332 Metric	2512 2512 (6432 Metric)	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR2B10DR003FTDG	3 mOhms	1 W		Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2		1206 (3216 Metric)	0.6 mm	0.024 in	1206	0.063 "	0.126 "	3.2 mm	1.6 mm
TE Connectivity AMP Connectors TLR2B10DR008FTDG	8 mOhms	1 W		Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2		1206 (3216 Metric)	0.6 mm	0.024 in	1206	0.063 "	0.126 "	3.2 mm	1.6 mm
TE Connectivity AMP Connectors TLR3A10ER005FTDG	5 mOhms	1 W	2512	Current Sense	100 ppm/°C	1 %	170 °C	-55 C	2	6332 Metric	2512 2512 (6432 Metric)	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR3A20WR007FTDG	7 mOhms	2 W	2512	Current Sense	75 ppm/°C	1 %	170 °C	-55 C	2	6332 Metric	2512 2512 (6432 Metric)	0.6 mm	0.024 in
TE Connectivity AMP Connectors TLR2H15DR001FTDG	1 mOhms	1.5 W	2010	Current Sense	50 ppm/░C	1 %	170 °C	-55 C	2		2010 (5025 Metric)	0.6 mm	0.024 in		0.1 in	0.201 "	5.1 mm	2.54 mm
