29098 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE 4PDT 5A 120V
| Part | Relay Type | Switching Voltage | Coil Resistance | Termination Style | Contact Material | Mounting Type | Operate Time | Approval Agency | Coil Voltage | Contact Rating (Current) | Operating Temperature [Min] | Operating Temperature [Max] | Coil Current | Features | Coil Type | Contact Form | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | General Purpose | 250 VAC 250 VDC | 9.23 kOhms | Screw Terminal | Silver Nickel (AgNi) | DIN Rail | 15 ms | CSA | 120 VAC | 5 A | -40 °C | 50 °C | 13 mA | Lighted Indicator Socket Included Varistor | Non Latching | 4PDT (4 Form C) | 20 ms |
 Phoenix Contact | General Purpose | 250 VAC 250 VDC | 1.33 kOhms | Screw Terminal | Silver Tin Oxide (AgSnO) | DIN Rail | 8 ms | CSA | 24 VDC | 6 A | -40 °C | 70 °C | 18 mA | Diode Lighted Indicator Socket Included | Non Latching | SPST-NO (1 Form A) | 10 ms |
 Phoenix Contact | General Purpose | 250 VAC 250 VDC | 571 Ohms | Screw Terminal | Silver Nickel (AgNi) | DIN Rail | 13 ms | ATEX cULus EAC IECEx UL | 24 VDC | 6 A | -40 °C | 60 °C | 42 mA | Diode Lighted Indicator Socket Included | Non Latching | 4PDT (4 Form C) | 14 ms |
 Phoenix Contact | General Purpose | 250 VAC 250 VDC | 35.39 kOhms | Screw Terminal | Silver Nickel (AgNi) | DIN Rail | 15 ms | CSA | 230 VAC | 5 A | -40 °C | 50 °C | 6.5 mA | Lighted Indicator Socket Included Varistor | Non Latching | 4PDT (4 Form C) | 20 ms |
