8501KP Series
Manufacturer: SCHNEIDER ELECTRIC
Beta
⌘K
RELAY 3CO CYL PIN 6.6A@240V 24VA
| Part | Contact Form | Contact Rating (Current) | Coil Voltage | Switching Voltage | Contact Material | Load - Max Switching | Termination Style | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Release Time | Operate Time | Relay Type | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHNEIDER ELECTRIC | 3PDT (3 Form C) | 10 A | 24 VAC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | 11 Pin | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Chassis Mount | |
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 12 VAC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Chassis Mount | ||
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 48 VDC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Chassis Mount | ||
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 24 VAC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Socketable | ||
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 24 VDC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Socketable | ||
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 240 VAC/DC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | 11 Pin | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Socketable | Lighted Indicator |
 SCHNEIDER ELECTRIC | DPDT (2 Form C) | 10 A | 24 VAC | 30 VDC 300 VAC | Silver Nickel (AgNi) | 300 W 3000 VA | 11 Pin | Plug In | 55 °C | -40 C | Non Latching | 20 ms | 20 ms | General Purpose | Chassis Mount | Lighted Indicator |
