Wall Mount Power Supply 5V 6 Watt
Wall Mount Power Supply 5V 6 Watt
| Part | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Applications | Input Connector | Voltage - Output | Current - Output (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Input Type | Polarization | Form | Region Utilized | Standard Number | Efficiency | Power (Watts) | Cord Length | Cord Length | Output Connector | Output Connector [diameter] | Output Connector [x] | No Load Power Consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | 32 mm | 55.9 mm | 1.26 " | 1.46 " | 37.1 mm | 2.2 in | CB CE cURus FCC TUV | 264 VAC | 90 VAC | Medical | Multi-Blade (Sold Separately) | 12 V | 500 mA | 0 °C | 60 °C | Multi-Blade (Sold Separately) | Positive Center | Wall Mount | International | 60601-1 | Level VI | 6 W | 70.9 " | 1.8 m | Barrel Plug | 2.1 mm 5.5 mm | 9.5 mm | 100 mW |
 TT Electronics/BI | 32 mm | 55.9 mm | 1.26 " | 1.46 " | 37.1 mm | 2.2 in | CB CE cURus FCC TUV | 264 VAC | 90 VAC | Medical | Multi-Blade (Sold Separately) | 5 V | 1.2 A | 0 °C | 60 °C | Multi-Blade (Sold Separately) | Wall Mount | International | 60601-1 | Level VI | 6 W | USB A Receptacle | 100 mW | |||||
TT Electronics/BI | 32 mm | 55.9 mm | 1.26 " | 1.46 " | 37.1 mm | 2.2 in | CB CE cURus FCC TUV | 264 VAC | 90 VAC | Medical | Multi-Blade (Sold Separately) | 5 V | 1.2 A | 0 °C | 60 °C | Multi-Blade (Sold Separately) | Positive Center | Wall Mount | International | 60601-1 | Level VI | 6 W | 70.9 " | 1.8 m | Barrel Plug | 2.1 mm 5.5 mm | 9.5 mm | 100 mW |
