MAX9030 Series

Catalog

IC COMPARATOR 1 GEN PUR SOT6

Part	Type	Supplier Device Package	Hysteresis	Current - Quiescent (Max) [Max]	Number of Elements	Package / Case	Voltage - Supply, Single/Dual (±) [Min]	Voltage - Supply, Single/Dual (±) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input Offset (Max) [Max]	CMRR, PSRR (Typ)	Output Type	Propagation Delay (Max) [Max]	Current - Input Bias (Max)	Mounting Type	Current - Output (Typ)
Analog Devices Inc./Maxim Integrated MAX9030AUT-T	General Purpose Standard (General Purpose)	SOT-23-6 SOT-6	4 mV	55 µA	1	SOT-23-6	2.5 V	5.5 V	125 °C	-40 C	1 mV	100 dB	Push-Pull Rail-to-Rail	228 ns	0.008 µA	Surface Mount
Analog Devices Inc./Maxim Integrated MAX9030AUT+T	General Purpose Standard (General Purpose)	SOT-23-6 SOT-6	4 mV	55 µA	1	SOT-23-6	2.5 V	5.5 V	125 °C	-40 C	1 mV	100 dB	Push-Pull Rail-to-Rail	228 ns	0.008 µA	Surface Mount
Analog Devices Inc./Maxim Integrated MAX9030AXT	General Purpose	SC-70-6	4 mV	55 µA	1	6-TSSOP SC-88 SOT-363	2.5 V	5.5 V	125 °C	-40 C	5 mV	100 dB 100 dB	Push-Pull Rail-to-Rail	228 ns	0.08 µA	Surface Mount	45 mA
Analog Devices Inc./Maxim Integrated MAX9030AXT+T	General Purpose Standard (General Purpose)	SC-70-6	4 mV	55 µA	1	6-TSSOP SC-88 SOT-363	2.5 V	5.5 V	125 °C	-40 C	1 mV	100 dB	Push-Pull Rail-to-Rail	228 ns	0.008 µA	Surface Mount
Analog Devices Inc./Maxim Integrated MAX9030AXT-T	General Purpose Standard (General Purpose)	SC-70-6	4 mV	55 µA	1	6-TSSOP SC-88 SOT-363	2.5 V	5.5 V	125 °C	-40 C	1 mV	100 dB	Push-Pull Rail-to-Rail	228 ns	0.008 µA	Surface Mount
