ZUW31212 Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
DC DC CONVERTER +/-12V 24V 3.1W
| Part | Current - Output (Max) | Current - Output (Max) | Mounting Type | Power (Watts) | Voltage - Input (Max) [Max] | Applications | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output 1 | Voltage - Input (Min) [Min] | Voltage - Isolation | Voltage - Output 2 | Type | Efficiency | Package / Case | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | 130 mA | 130 mA | Through Hole | 3.1 W | 18 V | ITE (Commercial) | 7 mm | 0.91 in | 23 mm | 0.28 " | 1.38 " | 35 mm | -20 °C | 71 °C | 12 V | 9 V | 500 V | -12 V | Isolated Module | 74 % | 5-DIP Module | 2 |
