LED Power Supplies 4W 230Vin 3-8Vout 500mA
LED Power Supplies 4W 230Vin 3-8Vout 500mA
| Part | Type | Topology | Termination Style | Features | Approval Agency | Ratings | Voltage - Output [Max] | Voltage - Output [Min] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Power (Watts) | Voltage - Isolation | Efficiency | Current - Output (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Outputs | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | Constant Current | AC DC Converter | Wire Leads | OCP OTP SCP | CB CE cETLus ENEC | IP65 | 12 V | 3 V | 0.83 " | 38 mm | 27 mm | 21 mm | 1.06 in | 1.5 in | 4 W | 3750 VDC | 77 % | 350 mA | -20 ░C | 50 °C | 1 | 264 VAC | 90 VAC | |
 Recom Power | Constant Current | AC DC Converter | Wire Leads | OCP OTP SCP | CB CE cETLus ENEC | IP65 | 8 V | 3 V | 0.83 " | 38 mm | 27 mm | 21 mm | 1.06 in | 1.5 in | 4 W | 3750 VDC | 75 % | 500 mA | -20 ░C | 50 °C | 1 | 264 VAC | 90 VAC | Chassis Mount |
 Recom Power | Constant Current | AC DC Converter | Wire Leads | OCP OTP SCP | CB CE cETLus ENEC | IP65 | 6 VDC | 3 V | 0.83 " | 38 mm | 27 mm | 21 mm | 1.06 in | 1.5 in | 4 W | 3750 VDC | 72 % | 700 mA | -20 ░C | 50 °C | 1 | 264 VAC | 90 VAC | Chassis Mount |
