E3FRA Series
Manufacturer: SWITCHCRAFT/CONXALL
Beta
⌘K
CONN PLUG FMALE XLR 3P GOLD SLDR
| Part | Connector Type | Orientation | Termination | Mounting Feature | Shell Material | Contact Material | Shielding | Contact Finish - Mating | Current Rating (Amps) | Color | Fastening Type | Shell Finish | Primary Material | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Features | Applications | Shell Size - Insert | Insert Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SWITCHCRAFT/CONXALL | Plug Female Sockets | Keyed | Solder | Flange | Zinc Die Cast | Copper Alloy | Shielded | Gold | 15 A | Silver | Latch Lock | Nickel | Metal | Panel Mount Right Angle Through Hole | -55 C | 85 °C | Board Guide Ground | Audio Instrumentation | XLR | Thermoplastic |
SWITCHCRAFT/CONXALL | Plug Female Sockets | Keyed | Solder | Flange | Zinc Die Cast | Copper Alloy | Shielded | Silver | 15 A | Black | Latch Lock | Chrome | Metal | Panel Mount Right Angle Through Hole | -55 C | 85 °C | Board Guide Ground | Audio Instrumentation | XLR | Thermoplastic |
SWITCHCRAFT/CONXALL | Insert Female Sockets | Keyed | Solder | Copper Alloy | Gold | 15 A | Right Angle Through Hole | -55 C | 85 °C | Insert Only Requires Shell | Audio Instrumentation | XLR | Thermoplastic | |||||||
 SWITCHCRAFT/CONXALL | Insert Female Sockets | Keyed | Solder | Copper Alloy | Silver | 15 A | Right Angle Through Hole | -55 C | 85 °C | Insert Only Requires Shell | Audio Instrumentation | XLR | Thermoplastic |
