CCG10 Series

Catalog

ISOLATED DC/DC CONVERTERS - SMD 10W 24VIN 12VOUT SINGLE SMD

Part	Current - Output (Max) [Max]	Number of Outputs	Efficiency	Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Isolation	Type	Control Features	Standard Number	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Applications	Package / Case	Voltage - Output 1	Mounting Type	Voltage - Input (Min) [Min]	Approval Agency	Voltage - Input (Max) [Max]	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2
TDK Corporation CCG10-24-12SR	900 mA	1	90 %	Adjustable Output OCP Remote On/Off	12.4 mm	0.46 in	19 mm	0.75 in	11.8 mm	0.49 "	1.5 kV	Isolated Module	Active Low Enable	62368-1	90 °C	-40 °C	11 W	ITE (Commercial)	6-SMD Module	12 V	Surface Mount	9 V	CE CSA EN IEC UKCA UL	36 V
TDK Corporation CCG10-48-15DF		2	89 %	OCP Remote On/Off	12.4 mm	0.45 in	19 mm	0.75 in	11.5 mm	0.49 "	1.5 kV	Isolated Module	Active Low Enable	62368-1	90 °C	-40 °C	10 W	ITE (Commercial)	6-DIP Module	15 V	Through Hole	18 V	CE CSA EN IEC UKCA UL	76 V	340 mA	340 mA	-15 V
