48ASSP1 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
SLIDE,SPDT,O-N-O,RAH,+TAB,LF
| Part | Electrical Life | Actuator Material | Switch Travel | Voltage Rating - AC | Termination Style | Contact Timing | Mounting Type | Actuator Type | Contact Finish | Actuator Length [x] | Current Rating (Amps) | Voltage Rating - DC | Operating Temperature [Max] | Operating Temperature [Min] | Switch Function | Circuit | Features | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Panel Mount Right Angle | Standard | Silver | 5.08 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Right Angle Through Hole | Standard | Silver | 5.08 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
 Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 20 V | PC Pin | Not Specified | Right Angle Through Hole | Standard | Gold | 7.24 mm | 0.4 VA | 20 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Through Hole | Standard | Silver | 9.4 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
 Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | Solder Lug | Not Specified | Panel Mount | Standard | Silver | 9.4 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Panel Mount | Standard | Silver | 5.08 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
 Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 20 V | PC Pin | Not Specified | Through Hole | Standard | Gold | 5.08 mm | 0.4 VA | 20 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Through Hole | Standard | Silver | 7.24 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 125 V | PC Pin | Not Specified | Panel Mount | Standard | Silver | 5.08 mm | 5 A | 28 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
Grayhill Inc. | 30000 Cycles | Polyamide (PA) Nylon | 2.16 mm | 20 V | PC Pin | Not Specified | Panel Mount Right Angle | Standard | Gold | 5.08 mm | 0.4 VA | 20 V | 85 °C | -30 ░C | On-On | SPDT | Epoxy Sealed Terminals | Copper Alloy |
