896-076 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 76POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Termination | Gender | Contact Finish | Read Out | Number of Positions | Contact Material | Flange Feature | Color | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Type | Card Type | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | M3 Threaded Insert Top Mount Opening | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount Side Opening Unthreaded | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount Side Opening Unthreaded | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount Top Opening Unthreaded | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount Side Opening Unthreaded | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Female | Gold | Dual | 76 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Black | Board Edge Straddle Mount | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Female | Gold | Dual | 76 | Copper Alloy | Floating Bobbin Top Mount Opening | Black | Through Hole | 125 °C | -40 C | 38 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Cantilever | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.116 " | 2.95 mm |
