G41MC7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT, STY 4, SZ
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Primary Material | Connector Type | Material Flammability Rating | Mounting Feature | Voltage Rating | Mounting Type | Current Rating (Amps) | Insert Material | Ingress Protection | Shell Material | Contact Material | Applications | Number of Positions | Color | Shielding | Fastening Type | Contact Finish - Mating | Shell Size - Insert | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
120 °C | -50 °C | C | Plastic | Receptacle Female Sockets | UL94 V-0 | Bulkhead - Rear Side Nut | 35 V | Panel Mount | 7.5 A | Polyetheretherketone (PEEK) | IP64/IP67 | Polysulfone (PSU) | Brass | Industrial Medical Testing Equipment & Measurement | 5 | Gray | Unshielded | Detent Lock Push-Pull | Gold | 1 | ||
120 °C | -50 °C | C | Plastic | Receptacle Female Sockets | UL94 V-0 | Bulkhead - Rear Side Nut | 37 V | Panel Mount | 10 A | Polyetheretherketone (PEEK) | IP64/IP67 | Polysulfone (PSU) | Brass | Industrial Medical Testing Equipment & Measurement | 4 | Gray White | Unshielded | Detent Lock Push-Pull | Gold | 1 | ||
120 °C | -50 °C | C | Plastic | Receptacle Female Sockets | UL94 V-0 | Bulkhead - Rear Side Nut | 25 V | Panel Mount | 4 A | Polyetheretherketone (PEEK) | IP64/IP67 | Polysulfone (PSU) | Brass | Industrial Medical Testing Equipment & Measurement | 14 | Gray Red | Unshielded | Detent Lock Push-Pull | Gold | 1 | ||
120 °C | -50 °C | C | Plastic | Receptacle Female Sockets | UL94 V-0 | Bulkhead - Rear Side Nut | 25 V | Panel Mount | 10 A | Polyetheretherketone (PEEK) | IP64/IP67 | Polysulfone (PSU) | Brass | Industrial Medical Testing Equipment & Measurement | 5 | Gray | Unshielded | Detent Lock Push-Pull | Gold | 1 | Crimp | |
120 °C | -50 °C | C | Plastic | Receptacle Female Sockets | UL94 V-0 | Bulkhead - Rear Side Nut | 10 V | Panel Mount | 7.5 A | Polyetheretherketone (PEEK) | IP64/IP67 | Polysulfone (PSU) | Brass | Industrial Medical Testing Equipment & Measurement | 8 | Gray Yellow | Unshielded | Detent Lock Push-Pull | Gold | 1 |
