ZCAT Series
Manufacturer: TDK Corporation
Beta
⌘K
FERRITE CLAMP ON CORES 27MM X 14.5MM X 10MM, -40 TO +85 DEGC, 25OHM(10MHZ TO 100MHZ)
| Part | Length | Length | Inner Dimension [x] | Inner Dimension [y] | Inner Dimension [y] | Inner Dimension [x] | Outer Dimension [x] | Outer Dimension [y] | Outer Dimension [x] | Outer Dimension [y] | Mounting Type | Design | Impedance @ Frequency | Type | Length [x] | Inner Dimension [z] | Inner Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 1.063 in | 27 mm | 7 mm | 4 mm | 0.157 " | 0.276 " | 14.5 mm | 10 mm | 0.571 in | 0.394 in | Free Hanging | Hinged (Snap On) | 70 Ohm | Flat | |||
 TDK Corporation | 35 mm | 15 mm | 0.591 in | 30 mm | 20 mm | 1.181 " | 0.787 " | Free Hanging | Hinged (Snap On) | 150 Ohm | Flat | 1.378 " | 5 mm | 0.197 in |
