CZE Series
Manufacturer: Rubycon
Beta
⌘K
ALUMINUM ORGANIC POLYMER CAPACITORS 63VDC 33UF +/-20 1700MA AEC-Q200
| Part | Type | Applications | Voltage - Rated | Ripple Current @ Low Frequency | Lifetime @ Temp. | Ratings | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Capacitance | Package / Case | Size / Dimension [diameter] | Size / Dimension [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | ESR (Equivalent Series Resistance) | Lead Spacing | Lead Spacing | Tolerance | Mounting Type | Ripple Current @ High Frequency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rubycon | Hybrid | Automotive | 63 V | 170 mA | 10000 Hrs | AEC-Q200 | 0.413 " | 10.5 mm | 33 ÁF | Can Radial | 0.315 in | 8 mm | -55 C | 105 ░C | 40 mOhm | 0.138 in | 3.5 mm | 20 % | Through Hole | 1.7 A |
