VCD40 Series

Manufacturer: CUI Inc.

Catalog

MODULE DC-DC 12VIN 3-OUT 3.3V/15V/-15V 6A/0.3A/-0.3A 40W 9-PIN

Part	Voltage - Output 1	Current - Output (Max)	Approval Agency	Standard Number	Type	Voltage - Input (Min) [Min]	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 3	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Input (Max) [Max]	Voltage - Isolation	Number of Outputs	Voltage - Output 2	Package / Case	Efficiency	Mounting Type	Features	Power (Watts)	Current - Output (Max) [Max]
CUI Inc. VCD40-D12-T315	3.3 V	6 A 300 mA	UL	60950-1	Isolated Module	9 V	ITE (Commercial)	85 °C	-40 C	-15 V	50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	18 V	1.5 kV	3	15 V	9-DIP Module	88 %	Through Hole	OTP OVP SCP	29 W
CUI Inc. VCD40-D24-D12	12 V	1.8 A	UL	60950-1	Isolated Module	18 V	ITE (Commercial)	85 °C	-40 C		50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	36 V	1.5 kV	2	-12 V	9-DIP Module	91 %	Through Hole	OTP OVP SCP	43 W
CUI Inc. VCD40-D48-S15	15 V		UL	60950-1	Isolated Module	36 V	ITE (Commercial)	85 °C	-40 C		50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	72 V	1.5 kV	1		9-DIP Module	92 %	Through Hole	OTP OVP SCP	40 W	2.666 A
CUI Inc. VCD40-D12-D15	15 V	1.4 A	UL	60950-1	Isolated Module	9 V	ITE (Commercial)	85 °C	-40 C		50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	18 V	1.5 kV	2	-15 V	9-DIP Module	90 %	Through Hole	OTP OVP SCP	42 W
CUI Inc. VCD40-D48-T515	5 V	6 A 300 mA	UL	60950-1	Isolated Module	36 V	ITE (Commercial)	85 °C	-40 C	-15 V	50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	72 V	1.5 kV	3	15 V	9-DIP Module	90 %	Through Hole	OTP OVP SCP	39 W
CUI Inc. VCD40-D12-T312	3.3 V		UL	60950-1	Isolated Module	9 V	ITE (Commercial)	85 °C	-40 C	-12 V	50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	18 V	1.5 kV	3	12 V	9-DIP Module	88 %	Through Hole	OTP OVP SCP	29 W
CUI Inc. VCD40-D12-T512	5 V		UL	60950-1	Isolated Module	9 V	ITE (Commercial)	85 °C	-40 C	-12 V	50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	18 V	1.5 kV	3	12 V	9-DIP Module	88 %	Through Hole	OTP OVP SCP	40 W
CUI Inc. VCD40-D48-T312	3.3 V		UL	60950-1	Isolated Module	36 V	ITE (Commercial)	85 °C	-40 C	-12 V	50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	72 V	1.5 kV	3	12 V	9-DIP Module	89 %	Through Hole	OTP OVP SCP	29 W
CUI Inc. VCD40-D12-S5	5 V		UL	60950-1	Isolated Module	9 V	ITE (Commercial)	85 °C	-40 C		50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	18 V	1.5 kV	1		9-DIP Module	89 %	Through Hole	OTP OVP SCP	40 W	8 A
CUI Inc. VCD40-D48-D15	15 V	1.4 A	UL	60950-1	Isolated Module	36 V	ITE (Commercial)	85 °C	-40 C		50.8 mm	2 in	0.4 "	2 in	10.2 mm	50.8 mm	72 V	1.5 kV	2	-15 V	9-DIP Module	91 %	Through Hole	OTP OVP SCP	42 W
