85230 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2CON 20AWG CLR SHLD
| Part | Shield Material | Shield Coverage | Operating Temperature [Min] | Operating Temperature [Max] | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Jacket (Insulation) Material | Conductor Insulation | Usage | Shield Type | Features | Length | Length | Number of Conductors | Jacket Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | -60 °C | 150 °C | Multi-Conductor | 0.02 " | 0.508 mm | 0.182 in | 4.62 mm | 20 AWG | 28 AWG | 7 | Copper Tinned | Ethylene Tetrafluoroethylene (ETFE) | Ethylene Tetrafluoroethylene (ETFE) | Audio Control Instrumentation | Foil | Drain Wire | 304.8 m | 1000 ft | 2 | Clear |
