090136 Series

Manufacturer: Molex

Catalog

CONN HEADER R/A 9POS 2.54MM

Part	Mounting Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Connector Type	Number of Positions	Material Flammability Rating	Insulation Height	Insulation Height	Contact Finish - Mating	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Style	Contact Finish - Post	Number of Rows	Insulation Material	Fastening Type	Applications	Pitch - Mating	Pitch - Mating	Contact Shape	Shrouding	Contact Length - Mating	Contact Length - Mating	Contact Type	Contact Length - Post	Contact Length - Post	Termination	Number of Positions Loaded	Contact Finish Thickness - Mating
Molex 0901362209	Through Hole Right Angle	3 µm	118.1 µin	Header	9	UL94 V-0	7.21 mm	0.284 in	Gold	Black	15 µin	0.38 µm	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901362112	Through Hole Right Angle			Header	12	UL94 V-0	7.21 mm	0.284 in		Black		118.1 µin	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All	3 µm
Molex 0901362215	Through Hole Right Angle	3 µm	118.1 µin	Header	15	UL94 V-0	7.21 mm	0.284 in	Gold	Black	15 µin	0.38 µm	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901361208	Through Hole	3 µm	118.1 µin	Header	8	UL94 V-0	10.9 mm	0.429 in	Gold	Black	15 µin	0.38 µm	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901362315
Molex 0901361303	Through Hole	3 µm	118.1 µin	Header		UL94 V-0	10.9 mm	0.429 in	Gold	Black	30 Áin	0.76 Ám	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901362302	Through Hole Right Angle	3 µm	118.1 µin	Header	2	UL94 V-0	7.21 mm	0.284 in	Gold	Black	30 Áin	0.76 Ám	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901361107	Through Hole			Header	7	UL94 V-0	10.9 mm	0.429 in		Black		118.1 µin	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All	3 µm
Molex 0901362306	Through Hole Right Angle	3 µm	118.1 µin	Header	6	UL94 V-0	7.21 mm	0.284 in	Gold	Black	30 Áin	0.76 Ám	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
Molex 0901362208	Through Hole Right Angle	3 µm	118.1 µin	Header	8	UL94 V-0	7.21 mm	0.284 in	Gold	Black	15 µin	0.38 µm	Brass	Board to Cable/Wire	Tin	1	Polyester Glass Filled	Latch Holder	Automotive General Purpose	0.1 in	2.54 mm	Square	Shrouded - 4 Wall	0.266 in	6.75 mm	Male Pin	0.114 in	2.9 mm	Solder	All
